Specifications

• Video:
  Input: Dynamic Hybrid
  DVR Oriented: 8 Channel 4in1 HD Analog (BNC) + 8 Channel IP (Over Network)*
  NVR Oriented: 0 Channel 4in1 HD Analog (BNC) + 16 Channel IP (Over Network)*
  *Including all the HD Analog/IP variations available within the specified ranges.
  Output: VGA: 1024x768/1280x1024/1920x1080
  HDMI: 1024x768/1280x1024/1920x1080 / 3840x2160(4K)
  CVBS (Can be used a spot)


• Recording:
  HD Analog – 0-8 Channels
  AHD/TVI: 8MP Lite
  Max 12/15FPS Per Channel
  Resolution: 3840x2160 (PAL/NTSC)
  AHD/TVI: 5MP
  Max 12FPS Per Channel
  Resolution: 2560x1936 (PAL/NTSC)
  AHD/TVI: 5MP Lite
  Max 20FPS Per Channel
  Resolution: 1280x1936 (PAL/NTSC)
  AHD/TVI/CVI: 4MP
  Max 12/15FPS Per Channel
  4MP Resolution: 2560x1440 (PAL/NTSC)
  AHD/TVI/CVI: 4MP Lite and lower
  Max 12/15FPS Per Channel
  4MP Resolution: 1280x1440 (PAL/NTSC)
  (Supported Resolutions: 1080P, 720P)
  CVBS: 960H
  Max 25/30FPS Per Channel
  Resolution: 960x575 (PAL) / 960x480 (NTSC)
  IP – 8-16 Channels
  IP: 8MP and lower
  Max 25/30FPS Per Channel
  Resolution: 3840x2160 (PAL/NTSC)


• Playback:
  8 Channel Simultaneously (Local/Remote)


• Analytics:
  For IP Channels: Line Crossing, Sterile Area, Object Monitoring, Camera Tampering and Smart Search.
  For HD Analog Channels: Line Crossing, Sterile Area and Smart Search.


• Bandwidth:
  Incoming: 32-64Mbps
  Outgoing: 96Mbps


• Audio:
  Input: 1 Channel (RCA) + IP Cameras inputs
  Output: 1 Channel (RCA) + IP Cameras outputs
  2 Way audio


• Storage:
  1 x SATA (Up to 6TB)


• USB Port:
  2 x USB2.0

• Network: RJ-45: 100Mbps


• Alarm:
  Input: IP Cameras inputs only
  Output: IP Cameras outputs only
