Specifications

• Video:
  Input: Dynamic Hybrid
  DVR Oriented: 4 Channel 4in1 HD Analog (BNC) + 2 Channel IP (Over Network)*
  NVR Oriented: 0 Channel 4in1 HD Analog (BNC) + 6 Channel IP (Over Network)*
  *Including all the HD Analog/IP variations available within the specified ranges.
  Output: VGA: 1024x768/1280x1024/1920x1080
  HDMI: 1024x768/1280x1024/1920x1080 / 3840x2160(4K)
  CVBS (Can be used a spot)


• Recording:
  HD Analog – 0-4 Channels
  AHD/TVI: 8MP Lite
  Max 12/15FPS Per Channel
  Resolution: 1920x2160 (PAL/NTSC)
  AHD/TVI: 5MP
  Max 12FPS Per Channel
  Resolution: 2560x1936 (PAL/NTSC)
  AHD/TVI: 5MP Lite
  Max 20FPS Per Channel
  Resolution: 1280x1936 (PAL/NTSC)
  AHD/TVI/CVI: 4MP
  Max 12/15FPS Per Channel
  4MP Resolution: 2560x1440 (PAL/NTSC)
  AHD/TVI/CVI: 4MP Lite and lower
  Max 25/30PS Per Channel
  4MP Resolution: 1280x1440 (PAL/NTSC)
  (Supported Resolutions: 1080P, 720P)
  CVBS: 960H
  Max 25/30FPS Per Channel
  Resolution: 960x575 (PAL) / 960x480 (NTSC)
  IP – 2-6 Channels
  IP: 8MP and lower
  Max 25/30FPS Per Channel
  Resolution: 3840x2160 (PAL/NTSC)


• Playback:
  4 Channel Simultaneously (Local)
  5 Channel Simultaneously (Remote)


• Analytics:
  For IP Channels: Line Crossing, Sterile Area, Object Monitoring, Camera Tampering and Smart Search.
  For HD Analog Channels: Line Crossing, Sterile Area and Smart Search.


• Bandwidth:
  Incoming: 16-36Mbps

Outgoing: 40Mbps

• Audio:
  Input: 1 Channel (RCA) + IP Cameras inputs
  Output: 1 Channel (RCA) + IP Cameras outputs
  2 Way audio


• Storage:
  1 x SATA (Up to 6TB)


• USB Port:
  2 x USB2.0

• Network: RJ-45: 100Mbps


• Alarm:
  IP Cameras inputs
  IP Cameras outputs


• PTZ / Keyboard:
  1 x RS485
  Protocol: CoC/Pelco D\P/Samsung/Visca (IP Over ONVIF)
