Specifications

• Video:
  Input: Dynamic Hybrid
  DVR Oriented: 32 Channel 4in1 HD Analog (BNC) + 32 Channel IP (Over Network)*
  NVR Oriented: 0 Channel 4in1 HD Analog (BNC) + 64 Channel IP (Over Network)*
  *Including all the HD Analog/IP variations available within the specified ranges.
  Output: VGA: 1024x768/1280x1024/1920x1080
  HDMI: 1024x768/1280x1024/1920x1080/4K
  CVBS (Can be used a spot)


• Recording:
  HD Analog – 0-32 Channels
  AHD/CVI/TVI: 8MP
  Max 8FPS Per Channel
  Resolution: 3860×2140 (PAL/NTSC)

  AHD/CVI/TVI: 8MP Lite
  Max 12/15FPS Per Channel
  Resolution: 1930×2140 (PAL/NTSC)

  AHD/TVI: 5MP
  Max 10FPS Per Channel
  Resolution: 2592x1944 (PAL/NTSC)

  AHD/TVI: 5MP Lite
  Max 20FPS Per Channel
  Resolution: 1296x1944 (PAL/NTSC)

  AHD/TVI/CVI: 4MP
  Max 12/15FPS Per Channel
  Resolution: 15600x1936 (PAL/NTSC)

  AHD/TVI/CVI: 4MP Lite / 2MP / 1MP
  Max 25/30FPS Per Channel
  Resolution: 1280x1936 (PAL/NTSC)

  CVBS: 960H
  Max 25/30FPS Per Channel
  Resolution: 960x575 (PAL) / 960x480 (NTSC)

  IP – 32-64 Channels

  IP: 8MP and lower
  Max 25/30FPS Per Channel
  Resolution: 3860×2140 (PAL/NTSC)


• Playback:
  16 Channel Simultaneously (Local)
  36 Channel Simultaneously (Remote)


• Bandwidth:
  Incoming: 160-320Mbps
  Outgoing: 320Mbps


• Audio:
  Input: 16 Channel (RCA)
  Output: 1 Channel (RCA)
  2 Way audio


• Storage:
  8 x SATA (Up to 8TB Each)
  1 x eSATA (Up to 8TB)
  RAID (0/1/5/6/10) Support


• USB Port:
  2 x USB2.0
  1 x USB3.0


• Network: 2 x RJ-45: 1000Mbps


• Alarm:
  Input: 16 (Dry-Contact)
  Output: 4 (Dry-Contact)


• PTZ / Keyboard:
  2 x RS485
  Protocol: CoC/Pelco D\P/Samsung/Visca (IP Over ONVIF)
