SH-4100A-2L(MM)

4 CH "4 In 1" + 1 CH IP Hybrid DVR

1080P Lite Real- Time • Input: 4CH AHD Standard BNC + 1CH IP (Over Network) • "All in 1" Hybrid (AHD / CVI / TVI / CVBS + IP) • Output: HDMI 1080P, VGA (1280x1024) • Audio In/Out

Provision ISR SH-4100A-2L(MM)
SH-4100A-2L(MM) Specs
Download Specs Download User Manual Latest Firmware Version - v1.3.5 - 19/03/2020 Latest CMS Version Latest CMS for MAC Latest IP Tool Video Player

Specifications

  • Video:
    Input: 4CH AHD Standard BNC + 1CH IP (Over Network) Output: HDMI 1080P, VGA (1280x1024),

  • Recording:
    AHD / CVI + TVI / 1080P Lite: 4CH Real-Time 100FPS (PAL)/120FPS (NTSC) Total. Up to 25/30FPS Per Channel AHD / CVI / TVI 720P /Analog: 4CH real-Time 100FPS (PAL)/120FPS (NTSC) Total. Up to 25/30FPS Per Channel

    IP channel: 1Ch- 1080P

    FPS: 25(PAL) / 30(NTSC)

  • Playback:

    • 4 Channel Simultaneously

  • Audio:
    Input: 1 Channel (RCA) Output: 1 Channel (RCA) 2 Way audio

  • Storage:
    1 x SATA (Up to 6TB)


  • USB Port:
    2 x USB2.0


  • Network:
    RJ-45: 100Mbps


  • PTZ / Keyboard:
    Supported Protocols: Pelco D, Pelco P, Samsung, Visca, ONVIF, CoC
