Specifications

• Video:
  Input: Dynamic Hybrid
  DVR Oriented: 32 Channel 4in1 HD Analog (BNC) + 8 Channel IP (Over Network)*
  NVR Oriented: 24 Channel 4in1 HD Analog (BNC) + 16 Channel IP (Over Network)*
  *Including all the HD Analog/IP variations available within the specified ranges.
  Output: VGA: 1024x768/1280x1024/1920x1080
  HDMI: 1024x768/1280x1024/1920x1080
  CVBS (Can be used a spot)


• Recording:
  HD Analog – 24-32 Channels
  AHD/TVI: 5MP Lite
  Max 10FPS Per Channel
  Resolution: 1280x1936 (PAL/NTSC)
  AHD/TVI: 4MP Lite
  Max 12/15FPS Per Channel
  Resolution: 1280x1936 (PAL/NTSC)
  AHD/TVI/CVI: 1080P
  Max 12/15FPS Per Channel
  Resolution: 1920x1080 (PAL/NTSC)
  (Supported Resolutions: 1080P Lite, 720P)
  CVBS: 960H
  Max 25/30FPS Per Channel
  Resolution: 960x575 (PAL) / 960x480 (NTSC)
  IP – 8-24 Channels
  IP: 5MP and lower
  Max 25/30FPS Per Channel
  Resolution: 2560x1920 (PAL/NTSC)


• Playback:
  16 Channel Simultaneously (Local)
  8 Channel Simultaneously (Remote)


• Bandwidth:
  Incoming: 40-88Mbps
  Outgoing: 160Mbps


• Audio:
  Input: 16 Channel (RCA)
  Output: 1 Channel (RCA)
  2 Way audio


• Storage:
  1 x eSATA (Up to 8TB)
  4 x SATA (Up to 8TB Each)


• USB Port:
  2 x USB2.0

• Network: RJ-45: 100Mbps


• Alarm:
  Input: 16 (Dry-Contact) Output: 4 (Dry-Contact)


• PTZ / Keyboard:
  1 x RS485
  Protocol: CoC/Pelco D\P/Samsung/Visca (IP Over ONVIF)
